80 Series Landcruiser Panhard Correction Kit (PCK)®

As your lift or load levels change the rear suspension ride height changes – so your “lift height” is rarely the advertised height (unless totally unladen, in some circumstances) and your static ride height is really determined by the accessories that are added to the rear of the truck and/or the typical load carried. Our PCK®s are designed to accommodate changes in static ride height or lift levels by providing multiple options for bar mounting.

Lift Heights:

• 50mm/2″ – use the lower hole on the axle bracket, stock hole on the frame side
• 75mm/3″ – use the upper hole on the axle bracket, stock hole on the frame
• 100mm/4″ – use the lower hole on the axle bracket and the new hole in the frame side bracket
• 125mm/5″ – use the upper hole on the axle bracket and the new hole in the frame side bracket


Includes:

• (1) Frame Side Drop Bracket
• (1) Axle Side Lift Bracket
• (1) eimkeith Logo Decal

To order, you’ll need to know what axle is in your FJ80/FZJ80 to select the appropriate kit for your truck.

You will either have a panhard mount with a forward (toward the front of the truck) side that has a flat or V-shaped upper edge. Order the corresponding kit for your axle.
